battery power thermal management
NF BTM1502
The Battery thermal management system features the following technical advantages: Integrated design for simplified installation; Modular structure supporting flexible expansion; Stable and reliable cooling and heating output; Surge-free heating with a linear curve and rapid temperature rise.
Quantity:
Our BMTS(Battery Thermal Management System) can be customized according to customer requirements.
Our BMTS(Battery Thermal Management System) can be customized according to customer requirements.
| Product Name | Battery thermal management system |
| Product Model Code | NFBTM10 |
| Refrigeration Capacity Test Condition | Ambient temperature 38ºC, outlet water temperature constant at 15ºC |
| Operating Ambient Temperature | -30 to +60ºC Refrigeration condition: -15ºC to +55ºC |
| Maximum Cooling Capacity | 10KW(8~24KW) (Optional) |
| Maximum Heating Capacity | 0~35Kw |
| Compressor Displacement | 33CC/46CC |
| Compressor Speed | 800~10000rpm/800~12000rpm |
| Coolant Type | 50%/50% Ethylene Glycol/Water Solution |
| Refrigerant Type | R134a |
| Communication Interface | CAN 2.0 Communication Rate: 500k bps |
| Control Method | Operating Mode + Target Water Temperature |
| COP | >2.2 |
| Coolant Flow Rate | >35L/min @ External Resistance 110kPa |
| Noise Level | <80dB (A) @ Maximum |
| Protection Rating | IP67 |
| Weight | <48kg/76KG |
| Low-voltage Power Supply Operating Range | 18~32V |
| High-voltage Power Supply Operating Range | ≤750V |
| Dimensions | L833W550H290mm/L900*W608*H341mm(excluding standard parts) |
| Inlet/Outlet Pipe Installation Diameter | Diameter 25mm |
Introduction:
The vehicle-grade battery cooling unit covers a cooling capacity of 8-15KW and a heating capacity of 10-24KW, providing battery cooling/heating for commercial vehicles (new energy heavy-duty trucks, new energy buses, new energy construction machinery), energy storage stations, battery swap stations, and other large-capacity battery applications
The vehicle-grade battery cooling unit covers a cooling capacity of 8-15KW and a heating capacity of 10-24KW, providing battery cooling/heating for commercial vehicles (new energy heavy-duty trucks, new energy buses, new energy construction machinery), energy storage stations, battery swap stations, and other large-capacity battery applications
Features:
1.Full-range temperature control
Combined low-temperature heating & high-temperature cooling (-30°C~50°C ambient) with ±1°C precision, maintaining optimal battery temperature for extended cycle life and improved energy efficiency.
2.Premium Product Emphasis
Advanced PID & energy-demand algorithms enable precise outlet temperature control (±0.5°C) with optimized energy efficiency. Features remote intelligent monitoring/diagnostics and OTA upgrade capability.
1.Full-range temperature control
Combined low-temperature heating & high-temperature cooling (-30°C~50°C ambient) with ±1°C precision, maintaining optimal battery temperature for extended cycle life and improved energy efficiency.
2.Premium Product Emphasis
Advanced PID & energy-demand algorithms enable precise outlet temperature control (±0.5°C) with optimized energy efficiency. Features remote intelligent monitoring/diagnostics and OTA upgrade capability.
