ptc water heater supplier
NF HVHQ30
This PTC coolant heater utilizes PTC technology, meeting the high-voltage safety requirements of passenger vehicles while also complying with relevant environmental requirements for engine compartment components.
Quantity:
The purpose of the PTC electric heater is to replace the engine block as the primary heat source, powering the PTC heating element to raise its temperature and then heating the medium in the system's circulating pipeline through heat exchange.
Its main performance characteristics are as follows:
Compact structure, high power density, and flexible adaptation to vehicle installation space.
Redundant sealing design improves system reliability.
| Model | NF HVH-Q30 |
| Rated voltage | 600V |
| Voltage range | 450-750V |
| Rated power | 30KW |
| Flow(L/h) | ＞3000 |
| Control signal | CAN |
| Protection level | IP67 |
| Weight | 10.5kg |
| Mounting dimension | 162*305mm |
