electronic coolant pump
NF352.4012
The 80W Electronic Water Pump for New Energy Vehicles is a low-voltage, low-power, and intelligent centrifugal coolant circulation pump specifically designed for the thermal management of pure electric and hybrid vehicles. Its primary function is to provide precise temperature control for the battery, electric motor, and power electronics; it serves as the mainstream standard component for small-scale loops and auxiliary cooling systems.
Quantity:
| Model | NF02.03.352.4012 |
| Rated Voltage | DC24V |
| Operating Voltage Range | 18-32V |
| Rated Power | 80W |
| Rated Operating Condition | When the pump head is 5m, the flow rate is >1700L/h, and the current is ≤3.5A |
| Maximum Head | >11m |
| Storage Temperature | -40~100°C |
| Operating Ambient Temperature | -40~100°C |
| Permissible Medium | Antifreeze |
| Service Life | >20000 hours |
| Protection Class | IP67 |
| Mating Connector Model | AMP282088-1 |
| Noise | ≤40dB measured at a distance of 1 meter |
| Product Function Introduction | High-temperature protection, reverse connection protection, undervoltage protection, overvoltage protection, dry-running protection, and locked-rotor protection |
The 80W electronic water pump is a modular fluid pump driven by a brushless DC motor (BLDC), featuring a power output of approximately 80 watts and typically operating at 12V or 24V. It achieves intelligent speed control via PWM or LIN/CAN bus, providing the coolant circulation power required for the thermal management systems of new energy vehicles.
