battery drive water pump
NF862.5107
Electronic water pumps are core components of the thermal management system for new energy vehicles. They primarily provide high-flow and precisely controllable coolant circulation for the motor, battery, electronic control system (the three core components), and fuel cell.
Quantity:
| Rated voltage(V) | DC24V |
| Working voltage range | DC18V~32V |
| Rated current | ≤29A |
| Rated power | 650W |
| Cold style | Water-cooled |
| Waterproofing Grade | IP68 |
| ated flow | ≥5400L/h@20m |
| Maximum Head | ≥25m |
| Noise | ≤65 dB at 1 m |
This electronic coolant pump is a water-cooled pump, characterized by high power density and low temperature rise
This electric water pump supports speed control via CAN communication to adjust its operating status. In addition to basic functions, the pump also features corresponding protection functions.
It has a compact structure, small size, and light weight, allowing for flexible adaptation to different system installation spaces.
This electric water pump is used in automotive engine main cooling, auxiliary cooling, battery pack cooling, and energy storage systems. It drives coolant flow to heat dissipation locations, enabling thermal control systems to achieve optimal performance and stable operation. The pump supports speed control via CAN communication. In addition to basic functions, it also features protection functions.
