ac electric compressor
NF NEA46CAE
The electric air conditioning compressor is the core of the automotive air conditioning system and the overall vehicle thermal management.
Its task is to drive the refrigerant cycle, providing cooling or heating (in heat pump systems) for the passenger compartment and cooling the power battery.
Its task is to drive the refrigerant cycle, providing cooling or heating (in heat pump systems) for the passenger compartment and cooling the power battery.
Quantity:
Model | NFEZC45 |
Type | Electric scroll |
Refrigerant | R134a/HF01234-yf |
Displacement | 46cc/r |
Speed range | 800-11000RPM |
Refrigerant Oil/Oil Volume | POE68S/150ML |
HV Rated Voltage | 630V(DC) |
LV Rated Voltage | 24VDC |
The electric air conditioning compressor is an electric-driven cooling unit designed specifically for pure electric/hybrid vehicles. It replaces the oil-lubricated compressor driven by the engine in traditional fuel vehicles. It directly compresses the refrigerant through the electric motor to provide cooling for the cabin and battery system. It is a core component of the thermal management system of new energy vehicles.
