Oil-free piston air compressor
NFHV2.2
Oil Free Piston Compressors
This classic compressor series is designed for ease of maintenance and environmental friendliness; > The HV series is equipped with two stable 24VDC high-speed fans, which are used to dissipate the heat from the oil-free piston compressors - nowadays, they are widely used in electric buses, electric trucks, small trucks, dental care, and construction machinery, among other fields.
This classic compressor series is designed for ease of maintenance and environmental friendliness; > The HV series is equipped with two stable 24VDC high-speed fans, which are used to dissipate the heat from the oil-free piston compressors - nowadays, they are widely used in electric buses, electric trucks, small trucks, dental care, and construction machinery, among other fields.
Quantity:
The cutting edges of Oilfree piston NF has more Long lasting working life than other similar compressor in the market;
Constantly working more than 18,000H;
100% Imported from Germany for Piston Head and O-ring seal, And even bearings;
IP67 protection level can make it working under the water;
Lower Maintenance needs,8000H SERIVCE FREE
| Model | Air delivery | Pressure | Power kw | Outlet size | Weight |
HV1.5 | 0.17 | 10bar | 1.5 | M22×1.5 | 32 |
HV2.2 | 0.22 | 10bar | 2.2 | M22×1.5 | 48 |
HV3.0 | 0.32 | 10bar | 3.0 | M22×1.5 | 48 |
HV4.0 | 0.38 | 10bar | 4.0 | M22×1.5 | 60 |
Application：
Medical: Oil-free compressors are used in medical facilities to supply clean, dry compressed air for various applications, including ventilators, anesthesia machines, and dental equipment, where air purity is critical to patient health.
Medical: Oil-free compressors are used in medical facilities to supply clean, dry compressed air for various applications, including ventilators, anesthesia machines, and dental equipment, where air purity is critical to patient health.
Pharmaceuticals: Pharmaceuticals manufacturing relies on oil-free air compressors to ensure product purity and prevent contamination in processes such as tablet coating, packaging, and air agitation of liquids.
Food and Beverage: Oil-free compressors are essential for the food and beverage industry to maintain product quality and safety. They are used for tasks like bottling, canning, and pneumatic conveying of food products.
Electronics: The electronics industry utilizes oil-free compressed air in cleanroom environments for semiconductor manufacturing, circuit board assembly, and sensitive instrument calibration.
Laboratories: Oil-free compressors are employed in research laboratories for various applications, such as chromatography, gas chromatograph-mass spectrometry (GC-MS), and general laboratory air supply.
Painting and Coating: In automotive, aerospace, and industrial painting applications, oil-free compressors are used to provide clean, dry air for spray guns and pneumatic paint systems to achieve a high-quality finish.
Environmental Testing: Environmental testing labs use oil-free compressors to provide precise and contamination-free air for environmental chambers, air sampling equipment, and pollution monitoring instruments.
Chemical Industry: In chemical processing and laboratories, oil-free compressors are used for air-driven chemical reactions, gas sample analysis, and chemical testing.
Automotive: Automotive manufacturing relies on oil-free compressors for applications like pneumatic tool operation, tire inflation, and paint shop processes, where oil contamination could affect product quality.
Printing: The printing industry uses oil-free compressed air for tasks like operating printing presses and maintaining consistent ink viscosity to ensure print quality.
Beverage Dispensing: Oil-free compressors are used in beverage dispensing systems, such as soda fountains and beer taps, to provide clean and odor-free air for carbonation and dispensing.
Wastewater Treatment: In wastewater treatment plants, oil-free compressors are used for aeration processes, ensuring that the air introduced into the water remains free of oil contaminants.
